【IaC】Colección de códigos de muestra de Amazon S3

📅 Creado: 2025/01/23, Actualizado: 2025/01/23 ⏱️ Tiempo estimado de lectura ~2 mins (400 palabras)

Amazon S3 es un servicio que crea almacenamiento de objetos en la nube de AWS.
Los datos guardados incluyen contenido estático, datos de respaldo, datos de archivo y archivos de registro en el sitio web.
En este artículo, describiremos la colección de códigos de muestra de la plantilla de Amazon S3 CloudFormation.

Índice

Coding Rules
Audit Log Bucket
Athena Work Group Query Result Bucket

Coding Rules

The CloudFormation template described in this article is based on CloudFormation/SAM Template Coding Rules .
Use CloudFormation Guard with a ruleset that evaluates compliance with the “Center for Internet Security (CIS) Amazon Web Services Foundation V1.4 Level 1” benchmark.
Use the following commands, as VS Code plugins cannot perform this evaluation.

cfn-guard validate \
--rules ~/cis-aws-benchmark-level-1.guard \
--data ./template.yml

Audit Log Bucket

The following CloudFormation template creates a bucket for storing audit logs output by AWS services.
The sources of the accumulated audit logs are AWS Config, AWS CloudTrail, Amazon GuardDuty, and Amazon VPC Flow Logs.
The log retention period is one year, and the retention period for multipart uploads and noncurrent files is 7 days.
A separate bucket is created for server access logs, which is set as the log destination for the audit log bucket.
As described in Amazon S3 server access logging now supports automatic date-based partitioning , server access logs can be partitioned by date, so the path is cut at the S3 event time.
The URLs of the sites referenced when designing the bucket policy and KMS key policy are included in the comments.
In the referenced documents, the Condition fields aws:SourceArn and aws:SourceAccount used the AWS account and resources of the log source, but these have been omitted in the following templates. At a minimum, access from IAM users and roles is denied, as the AWS service name is restricted by the Principal .
There is a risk of logs being output from unexpected AWS accounts due to design mistakes, so please add Condition statements as needed.
The design is based primarily on CIS and CFN_NAG rules.

AWSTemplateFormatVersion: 2010-09-09
Resources:
  AuditLogBucket01:
    Type: AWS::S3::Bucket
    Properties:
      BucketName: !Sub sample-audit-bucket-${AWS::AccountId}-${AWS::Region}
      BucketEncryption:
        ServerSideEncryptionConfiguration:
          - ServerSideEncryptionByDefault:
              KMSMasterKeyID: !GetAtt AuditLogKey01.Arn
              SSEAlgorithm: aws:kms
      OwnershipControls:
        Rules:
          - ObjectOwnership: BucketOwnerEnforced
      LifecycleConfiguration:
        Rules:
          - Status: Enabled
            AbortIncompleteMultipartUpload:
              DaysAfterInitiation: 7
            NoncurrentVersionExpirationInDays: 7
          - Status: Enabled
            ExpirationInDays: 365
            Prefix: /
      PublicAccessBlockConfiguration:
        BlockPublicAcls: true
        BlockPublicPolicy: true
        IgnorePublicAcls: true
        RestrictPublicBuckets: true
      VersioningConfiguration:
        Status: Enabled
      LoggingConfiguration:
        DestinationBucketName: !Ref ServerAccessLogBucket01
        TargetObjectKeyFormat:
          PartitionedPrefix:
            PartitionDateSource: EventTime

  AuditLogBucketPolicy01:
    Type: AWS::S3::BucketPolicy
    Properties:
      Bucket: !Ref AuditLogBucket01
      PolicyDocument:
        Version: 2012-10-17
        Statement:
          # Reference: https://docs.aws.amazon.com/config/latest/developerguide/s3-bucket-policy.html
          - Sid: AWSConfigAclCheck
            Effect: Allow
            Principal:
              Service: config.amazonaws.com
            Action:
              - s3:GetBucketAcl
            Resource: !Sub arn:${AWS::Partition}:s3:::${AuditLogBucket01}
          - Sid: AWSConfigWrite
            Effect: Allow
            Principal:
              Service: config.amazonaws.com
            Action:
              - s3:PutObject
              - s3:PutObjectAcl
            Resource: !Sub arn:${AWS::Partition}:s3:::${AuditLogBucket01}/*
          # Reference: https://docs.aws.amazon.com/awscloudtrail/latest/userguide/create-s3-bucket-policy-for-cloudtrail.html
          - Sid: AWSCloudTrailAclCheck
            Effect: Allow
            Principal:
              Service: cloudtrail.amazonaws.com
            Action:
              - s3:GetBucketAcl
            Resource: !Sub arn:${AWS::Partition}:s3:::${AuditLogBucket01}
          - Sid: AWSCloudTrailWrite
            Effect: Allow
            Principal:
              Service: cloudtrail.amazonaws.com
            Action:
              - s3:PutObject
            Resource: !Sub arn:${AWS::Partition}:s3:::${AuditLogBucket01}/AWSLogs/*
            Condition:
              StringEquals:
                s3:x-amz-acl: bucket-owner-full-control
          # Reference: https://docs.aws.amazon.com/guardduty/latest/ug/guardduty_exportfindings.html#guardduty_exportfindings-s3-policies
          - Sid: AllowPutObject
            Effect: Allow
            Principal:
              Service: guardduty.amazonaws.com
            Action: s3:PutObject
            Resource: !Sub arn:${AWS::Partition}:s3:::${AuditLogBucket01}/*
          - Sid: AllowGetBucketLocation
            Effect: Allow
            Principal:
              Service: guardduty.amazonaws.com
            Action: s3:GetBucketLocation
            Resource: !Sub arn:${AWS::Partition}:s3:::${AuditLogBucket01}
          # Reference: https://docs.aws.amazon.com/vpc/latest/tgw/flow-logs-s3.html#flow-logs-s3-permissions
          - Sid: VPCFlowLogsWrite
            Effect: Allow
            Principal:
              Service: delivery.logs.amazonaws.com
            Action:
              - s3:PutObject
            Resource: !Sub arn:${AWS::Partition}:s3:::${AuditLogBucket01}/*
            Condition:
              StringEquals:
                s3:x-amz-acl: bucket-owner-full-control
          - Sid: AWSLogDeliveryAclCheck
            Effect: Allow
            Principal:
              Service: delivery.logs.amazonaws.com
            Action:
              - s3:GetBucketAcl
              - s3:ListBucket
            Resource: !Sub arn:${AWS::Partition}:s3:::${AuditLogBucket01}
          # Reference: https://docs.aws.amazon.com/securityhub/latest/userguide/s3-controls.html#s3-5
          - Sid: AllowSSLRequestsOnly
            Effect: Deny
            Principal: '*'
            Action: s3:*
            Resource:
              - !Sub arn:${AWS::Partition}:s3:::${AuditLogBucket01}
              - !Sub arn:${AWS::Partition}:s3:::${AuditLogBucket01}/*
            Condition:
              Bool:
                aws:SecureTransport: false

  ServerAccessLogBucket01:
    Type: AWS::S3::Bucket
    Metadata:
      cfn_nag:
        rules_to_suppress:
          - id: W35
            reason: There is no need to record the server access log bucket itself
      guard:
        SuppressedRules:
          - S3_BUCKET_LOGGING_ENABLED # There is no need to record the server access log bucket itself
    Properties:
      BucketName: !Sub sample-server-access-log-bucket-${AWS::AccountId}-${AWS::Region}
      BucketEncryption:
        # Since SSE-KMS is not supported, use SSE-S3
        # Reference: https://docs.aws.amazon.com/AmazonS3/latest/userguide/enable-server-access-logging.html
        ServerSideEncryptionConfiguration:
          - ServerSideEncryptionByDefault:
              SSEAlgorithm: AES256
      OwnershipControls:
        Rules:
          - ObjectOwnership: BucketOwnerEnforced
      LifecycleConfiguration:
        Rules:
          - Status: Enabled
            AbortIncompleteMultipartUpload:
              DaysAfterInitiation: 7
            NoncurrentVersionExpirationInDays: 7
          - Status: Enabled
            ExpirationInDays: 365
            Prefix: /
      PublicAccessBlockConfiguration:
        BlockPublicAcls: true
        BlockPublicPolicy: true
        IgnorePublicAcls: true
        RestrictPublicBuckets: true
      VersioningConfiguration:
        Status: Enabled

  ServerAccessLogBucketPolicy01:
    Type: AWS::S3::BucketPolicy
    Properties:
      Bucket: !Ref ServerAccessLogBucket01
      PolicyDocument:
        Version: 2012-10-17
        Statement:
          # Reference: https://docs.aws.amazon.com/AmazonS3/latest/userguide/enable-server-access-logging.html#grant-log-delivery-permissions-general
          - Sid: S3ServerAccessLogsPolicy
            Effect: Allow
            Principal:
              Service: logging.s3.amazonaws.com
            Action: s3:PutObject
            Resource: !Sub arn:${AWS::Partition}:s3:::${ServerAccessLogBucket01}/*
          # Reference: https://docs.aws.amazon.com/securityhub/latest/userguide/s3-controls.html#s3-5
          - Sid: AllowSSLRequestsOnly
            Effect: Deny
            Principal: '*'
            Action: s3:*
            Resource:
              - !Sub arn:${AWS::Partition}:s3:::${ServerAccessLogBucket01}
              - !Sub arn:${AWS::Partition}:s3:::${ServerAccessLogBucket01}/*
            Condition:
              Bool:
                aws:SecureTransport: false

  AuditLogKey01:
    Type: AWS::KMS::Key
    UpdateReplacePolicy: Retain
    DeletionPolicy: Retain
    Properties:
      EnableKeyRotation: true
      RotationPeriodInDays: 365
      KeyPolicy:
        Version: 2012-10-17
        Statement:
          - Sid: EnableIAMUserPermissions
            Effect: Allow
            Principal:
              AWS: !Ref AWS::AccountId
            Action: kms:*
            Resource: '*'
          # Reference: https://docs.aws.amazon.com/guardduty/latest/ug/guardduty_exportfindings.html
          - Sid: AllowGuardDutyKey
            Effect: Allow
            Principal:
              Service: guardduty.amazonaws.com
            Action: kms:GenerateDataKey
            Resource: '*'

Athena Work Group Query Result Bucket

The following CloudFormation template creates a bucket for storing Athena work group query results.
The query result location can be set for each Athena work group.
Reference: Specify a query result location - Amazon Athena
The destination for server access logs is set to the server access log bucket defined in the audit log bucket section above.
As described in Amazon S3 server access logging now supports automatic date-based partitioning , server access logs can be partitioned by date, so the path is cut at the S3 event time.
The log retention period is 45 days, matching the period for which query history is maintained.
View recent queries in the Athena console - Amazon Athena
The AWS user guide does not provide specific information on S3 bucket policies, but allowing s3:PutObject and s3:GetBucketLocation actions enables access from Athena.

AWSTemplateFormatVersion: 2010-09-09
Resources:
  AthenaBucket01:
    Type: AWS::S3::Bucket
    Properties:
      BucketName: !Sub sample-athena-bucket-${AWS::AccountId}-${AWS::Region}
      BucketEncryption:
        ServerSideEncryptionConfiguration:
          - ServerSideEncryptionByDefault:
              SSEAlgorithm: AES256
      LifecycleConfiguration:
        Rules:
          - Status: Enabled
            ExpirationInDays: 45
            Prefix: athena/
          - Status: Enabled
            AbortIncompleteMultipartUpload:
              DaysAfterInitiation: 7
            NoncurrentVersionExpirationInDays: 7
      PublicAccessBlockConfiguration:
        BlockPublicAcls: true
        BlockPublicPolicy: true
        IgnorePublicAcls: true
        RestrictPublicBuckets: true
      LoggingConfiguration:
        DestinationBucketName: !Sub sample-server-access-log-bucket-${AWS::AccountId}-${AWS::Region}
        TargetObjectKeyFormat:
          PartitionedPrefix:
            PartitionDateSource: EventTime
      VersioningConfiguration:
        Status: Enabled

  AthenaBucketPolicy01:
    Type: AWS::S3::BucketPolicy
    Properties:
      Bucket: !Ref AthenaBucket01
      PolicyDocument:
        Version: 2012-10-17
        Statement:
          - Sid: AllowAthenaGetBucketLocation
            Effect: Allow
            Principal:
              Service:
                - !Sub athena.${AWS::Region}.amazonaws.com
            Action:
              - s3:GetBucketLocation
              - s3:PutObject
            Resource:
              - !Sub arn:${AWS::Partition}:s3:::${AthenaBucket01}
              - !Sub arn:${AWS::Partition}:s3:::${AthenaBucket01}/*
          # Reference: https://docs.aws.amazon.com/securityhub/latest/userguide/s3-controls.html#s3-5
          - Sid: AllowSSLRequestsOnly
            Effect: Deny
            Principal: '*'
            Action: s3:*
            Resource:
              - !Sub arn:${AWS::Partition}:s3:::${AthenaBucket01}
              - !Sub arn:${AWS::Partition}:s3:::${AthenaBucket01}/*
            Condition:
              Bool:
                aws:SecureTransport: false
