【IaC】Amazon VPC sample code collection

Created date: 2025/05/28, Update date: 2025/07/21

Amazon VPC is a service that builds a virtual private cloud within the AWS cloud.
By using VPC, you can build your own network within the AWS cloud.
This article provides a sample code collection of Amazon VPC CloudFormation templates.

Table of Contents

Coding Rules
VPC

Coding Rules

The CloudFormation templates in this article follow the “IaC: CloudFormation Template / SAM Template Coding Rules” .
CloudFormation Guard is used, and a ruleset that evaluates compliance with the “Center for Internet Security (CIS) Amazon Web Services Foundation v1.4 Level 1” is applied.
- Since evaluation cannot be performed with the VSCode plugin, use the following command:

cfn-guard validate \
--rules ~/cis-aws-benchmark-level-1.guard \
--data ./template.yml

VPC

The following diagram illustrates the VPC configuration created by the CloudFormation template.
AWS::EC2::RouteTable , AWS::EC2::Route , AWS::EC2::SubnetRouteTableAssociation ,
AWS::EC2::NetworkAcl , AWS::EC2::NetworkAclEntry , and AWS::EC2::SubnetNetworkAclAssociation ,
as well as AWS::EC2::EIP , are not shown in the diagram but are included in the VPC configuration.

flowchart LR %%{init:{"theme":"neutral"}}%% subgraph aws["AWS Account"] subgraph vpc-vvvv1["VPC (10.0.0.0/16)"] subgraph public1["sample-public1"] NAT1@{icon: "logos:Res_Amazon-VPC_NAT-Gateway", label: "sample-natgw1", pos: "b", h: 40} end subgraph public2["sample-public2"] NAT2@{icon: "logos:Res_Amazon-VPC_NAT-Gateway", label: "sample-natgw2", pos: "b", h: 40} end subgraph private1["sample-private1"] EC2-1@{icon: "logos:Res_Amazon-EC2_Instance", label: "EC2 Instance (not defined)", pos: "b", h: 40} end subgraph private2["sample-private2"] EC2-2@{icon: "logos:Res_Amazon-EC2_Instance", label: "EC2 Instance (not defined)", pos: "b", h: 40} end subgraph protected1["sample-protected1"] RDS1@{icon: "logos:Arch_Amazon-RDS", label: "RDS Instance (not defined)", pos: "b", h: 40} end subgraph protected2["sample-protected2"] RDS2@{icon: "logos:Arch_Amazon-RDS", label: "RDS Instance (not defined)", pos: "b", h: 40} end public2 ~~~ private2 ~~~ protected2 public1 ~~~ private1 ~~~ protected1 IGW@{icon: "logos:Res_Amazon-VPC_Internet-Gateway", label: "sample-igw", pos: "b", h: 40} end subgraph global-services1[" "] IAMRole1@{icon: "logos:Res_AWS-Identity-Access-Management_Role", label: "sample-flow-logs-role", pos: "b", h: 40} end subgraph global-services2[" "] FlowLog1@{icon: "logos:Res_Amazon-VPC_Flow-Logs", label: "sample-vpc-s3-flow-log", pos: "b", h: 40} S3Flow1@{icon: "logos:Res_Amazon-Simple-Storage-Service_Bucket", label: "S3 bucket (not defined)", pos: "b", h: 40} end subgraph global-services3[" "] FlowLog2@{icon: "logos:Res_Amazon-VPC_Flow-Logs", label: "sample-vpc-cloudwatch-logs-flow-log", pos: "b", h: 40} CWLogs1@{icon: "logos:Res_Amazon-CloudWatch_Logs", label: "/aws/vpc/flow-logs", pos: "b", h: 40} end vpc-vvvv1 ~~~ global-services1 vpc-vvvv1 ~~~ global-services2 vpc-vvvv1 ~~~ global-services3 end classDef group fill:none,stroke:none classDef vpc fill:none,color:#0a0,stroke:#0a0 classDef public fill:#def,color:#07b,stroke:none classDef private fill:#efe,color:#092,stroke:none style aws fill:#fff,color:#345,stroke:#345 class vpc-vvvv1 vpc class public1 public class public2 public class private1 private class private2 private class protected1 private class protected2 private class global-services1,global-services2,global-services3 group

The following CloudFormation template creates a VPC.
You can customize the VPC configuration using these parameters:
- DestinationVPCFlowLogBucketName : S3 bucket name for VPC flow logs
- EnableCloudWatchLogsVPCFlowLog : Whether to send VPC flow logs to CloudWatch Logs
- NatGatewayNum : Number of NAT Gateways (0, 1, or 2)
The CIDR blocks for the VPC and subnets are defined in the Mappings section. Please modify them to fit your design.
VPC endpoints and security groups are not included in this template.
- Since VPCs rarely change during operations, it is recommended to manage VPC endpoints and security groups—which have shorter change lifecycles—in separate templates.

AWSTemplateFormatVersion: 2010-09-09
Description: template.yml
Parameters:
  DestinationVPCFlowLogBucketName:
    Type: String
    Default: ""

  EnableCloudWatchLogsVPCFlowLog:
    Type: String
    AllowedValues:
      - 'true'
      - 'false'
    Default: 'false'

  NatGatewayNum:
    Type: String
    AllowedValues:
      - '0'
      - '1'
      - '2'
    Default: '0'

Conditions:
  CreateNatGateway: !Not [ !Equals [ !Ref NatGatewayNum, '0' ] ]
  UseNatGateway1: !Or [ !Equals [ !Ref NatGatewayNum, '1' ], !Equals [ !Ref NatGatewayNum, '2' ] ]
  UseNatGateway2: !Equals [ !Ref NatGatewayNum, '2' ]
  EnableVPCFlowLog: !Or [ !Not [ !Equals [ !Ref DestinationVPCFlowLogBucketName, "" ] ], !Equals [ !Ref EnableCloudWatchLogsVPCFlowLog, 'true' ] ]
  EnableS3VPCFlowLog: !Not [ !Equals [!Ref DestinationVPCFlowLogBucketName, "" ] ]
  EnableCloudWatchLogsVPCFlowLog: !Not [ !Equals [!Ref EnableCloudWatchLogsVPCFlowLog, 'false' ] ]

Mappings:
  VPC:
    VPC1:
      CIDR: 10.0.0.0/16

  Subnet:
    PublicSubnet1:
      CIDR: 10.0.0.0/20
    PublicSubnet2:
      CIDR: 10.0.16.0/20
    PrivateSubnet1:
      CIDR: 10.0.32.0/20
    PrivateSubnet2:
      CIDR: 10.0.48.0/20
    ProtectedSubnet1:
      CIDR: 10.0.64.0/22
    ProtectedSubnet2:
      CIDR: 10.0.68.0/22

Resources:
  VPC1:
    Type: AWS::EC2::VPC
    Properties:
      CidrBlock: !FindInMap [ VPC, VPC1, CIDR ]
      EnableDnsSupport: true
      EnableDnsHostnames: true
      Tags:
        - Key: Name
          Value: sample-vpc

  InternetGateway:
    Type: AWS::EC2::InternetGateway
    Properties:
      Tags:
        - Key: Name
          Value: sample-igw

  VPCGatewayAttachment:
    Type: AWS::EC2::VPCGatewayAttachment
    Properties:
      VpcId: !Ref VPC1
      InternetGatewayId: !Ref InternetGateway

  PublicSubnet1:
    Type: AWS::EC2::Subnet
    Metadata:
      cfn_nag:
        rules_to_suppress:
          - id: W33
            reason: "This is a public subnet."
    Properties:
      VpcId: !Ref VPC1
      CidrBlock: !FindInMap [ Subnet, PublicSubnet1, CIDR ]
      AvailabilityZone: !Select [ 0, !GetAZs '' ]
      MapPublicIpOnLaunch: true
      Tags:
        - Key: Name
          Value: sample-public1

  PublicSubnet2:
    Type: AWS::EC2::Subnet
    Metadata:
      cfn_nag:
        rules_to_suppress:
          - id: W33
            reason: "This is a public subnet."
    Properties:
      VpcId: !Ref VPC1
      CidrBlock: !FindInMap [ Subnet, PublicSubnet2, CIDR ]
      AvailabilityZone: !Select [ 1, !GetAZs '' ]
      MapPublicIpOnLaunch: true
      Tags:
        - Key: Name
          Value: sample-public2

  PrivateSubnet1:
    Type: AWS::EC2::Subnet
    Properties:
      VpcId: !Ref VPC1
      CidrBlock: !FindInMap [ Subnet, PrivateSubnet1, CIDR ]
      AvailabilityZone: !Select [ 0, !GetAZs '' ]
      MapPublicIpOnLaunch: false
      Tags:
        - Key: Name
          Value: sample-private1

  PrivateSubnet2:
    Type: AWS::EC2::Subnet
    Properties:
      VpcId: !Ref VPC1
      CidrBlock: !FindInMap [ Subnet, PrivateSubnet2, CIDR ]
      AvailabilityZone: !Select [ 1, !GetAZs '' ]
      MapPublicIpOnLaunch: false
      Tags:
        - Key: Name
          Value: sample-private2

  ProtectedSubnet1:
    Type: AWS::EC2::Subnet
    Properties:
      VpcId: !Ref VPC1
      CidrBlock: !FindInMap [ Subnet, ProtectedSubnet1, CIDR ]
      AvailabilityZone: !Select [ 0, !GetAZs '' ]
      MapPublicIpOnLaunch: false
      Tags:
        - Key: Name
          Value: sample-protected1

  ProtectedSubnet2:
    Type: AWS::EC2::Subnet
    Properties:
      VpcId: !Ref VPC1
      CidrBlock: !FindInMap [ Subnet, ProtectedSubnet2, CIDR ]
      AvailabilityZone: !Select [ 1, !GetAZs '' ]
      MapPublicIpOnLaunch: false
      Tags:
        - Key: Name
          Value: sample-protected2

  NATGateway1EIP:
    Type: AWS::EC2::EIP
    Condition: UseNatGateway1
    DependsOn: VPCGatewayAttachment
    Properties:
      Domain: vpc
      Tags:
        - Key: Name
          Value: sample-nat-eip1

  NatGateway1:
    Type: AWS::EC2::NatGateway
    Condition: UseNatGateway1
    Properties:
      AllocationId: !GetAtt NATGateway1EIP.AllocationId
      SubnetId: !Ref PublicSubnet1
      Tags:
        - Key: Name
          Value: sample-natgw1

  NATGateway2EIP:
    Type: AWS::EC2::EIP
    Condition: UseNatGateway2
    DependsOn: VPCGatewayAttachment
    Properties:
      Domain: vpc
      Tags:
        - Key: Name
          Value: sample-nat-eip2

  NatGateway2:
    Type: AWS::EC2::NatGateway
    Condition: UseNatGateway2
    Properties:
      AllocationId: !GetAtt NATGateway2EIP.AllocationId
      SubnetId: !Ref PublicSubnet2
      Tags:
        - Key: Name
          Value: sample-natgw2

  PublicRouteTable:
    Type: AWS::EC2::RouteTable
    Properties:
      VpcId: !Ref VPC1
      Tags:
        - Key: Name
          Value: sample-public-rt

  PublicRoute:
    Type: AWS::EC2::Route
    DependsOn: VPCGatewayAttachment
    Properties:
      RouteTableId: !Ref PublicRouteTable
      DestinationCidrBlock: 0.0.0.0/0
      GatewayId: !Ref InternetGateway

  PublicSubnet1RouteTableAssociation:
    Type: AWS::EC2::SubnetRouteTableAssociation
    Properties:
      SubnetId: !Ref PublicSubnet1
      RouteTableId: !Ref PublicRouteTable

  PublicSubnet2RouteTableAssociation:
    Type: AWS::EC2::SubnetRouteTableAssociation
    Properties:
      SubnetId: !Ref PublicSubnet2
      RouteTableId: !Ref PublicRouteTable

  PrivateSubnet1RouteTable:
    Type: AWS::EC2::RouteTable
    Condition: CreateNatGateway
    Properties:
      VpcId: !Ref VPC1
      Tags:
        - Key: Name
          Value: sample-private-rt

  PrivateSubnet1Route:
    Type: AWS::EC2::Route
    Condition: CreateNatGateway
    Properties:
      RouteTableId: !Ref PrivateSubnet1RouteTable
      DestinationCidrBlock: 0.0.0.0/0
      NatGatewayId: !If [ UseNatGateway1, !Ref NatGateway1, !Ref NatGateway2 ]

  PrivateSubnet1RouteTableAssociation:
    Type: AWS::EC2::SubnetRouteTableAssociation
    Condition: CreateNatGateway
    Properties:
      SubnetId: !Ref PrivateSubnet1
      RouteTableId: !Ref PrivateSubnet1RouteTable

  PrivateSubnet2RouteTable:
    Type: AWS::EC2::RouteTable
    Condition: CreateNatGateway
    Properties:
      VpcId: !Ref VPC1
      Tags:
        - Key: Name
          Value: sample-private-rt

  PrivateSubnet2Route:
    Type: AWS::EC2::Route
    Condition: CreateNatGateway
    Properties:
      RouteTableId: !Ref PrivateSubnet2RouteTable
      DestinationCidrBlock: 0.0.0.0/0
      NatGatewayId: !If [ UseNatGateway2, !Ref NatGateway2, !Ref NatGateway1 ]

  PrivateSubnet2RouteTableAssociation:
    Type: AWS::EC2::SubnetRouteTableAssociation
    Condition: CreateNatGateway
    Properties:
      SubnetId: !Ref PrivateSubnet2
      RouteTableId: !Ref PrivateSubnet2RouteTable

  ProtectedRouteTable:
    Type: AWS::EC2::RouteTable
    Properties:
      VpcId: !Ref VPC1
      Tags:
        - Key: Name
          Value: sample-protected-rt

  ProtectedSubnet1RouteTableAssociation:
    Type: AWS::EC2::SubnetRouteTableAssociation
    Properties:
      SubnetId: !Ref ProtectedSubnet1
      RouteTableId: !Ref ProtectedRouteTable

  ProtectedSubnet2RouteTableAssociation:
    Type: AWS::EC2::SubnetRouteTableAssociation
    Properties:
      SubnetId: !Ref ProtectedSubnet2
      RouteTableId: !Ref ProtectedRouteTable

  CustomNetworkAcl:
    Type: AWS::EC2::NetworkAcl
    Properties:
      VpcId: !Ref VPC1
      Tags:
        - Key: Name
          Value: sample-custom-nacl

  CustomNetworkAclEntryInbound:
    Type: AWS::EC2::NetworkAclEntry
    Metadata:
      cfn_nag:
        rules_to_suppress:
          - id: W66
            reason: "This rule allows all inbound traffic, which is necessary for the VPC to function properly."
    Properties:
      NetworkAclId: !Ref CustomNetworkAcl
      RuleNumber: 100
      Protocol: -1
      RuleAction: allow
      Egress: false
      CidrBlock: 0.0.0.0/0

  CustomNetworkAclEntryOutbound:
    Type: AWS::EC2::NetworkAclEntry
    Metadata:
      cfn_nag:
        rules_to_suppress:
          - id: W66
            reason: "This rule allows all outbound traffic, which is necessary for the VPC to function properly."
    Properties:
      NetworkAclId: !Ref CustomNetworkAcl
      RuleNumber: 100
      Protocol: -1
      RuleAction: allow
      Egress: true
      CidrBlock: 0.0.0.0/0

  NaclAssociationPublicSubnet1:
    Type: AWS::EC2::SubnetNetworkAclAssociation
    Properties:
      SubnetId: !Ref PublicSubnet1
      NetworkAclId: !Ref CustomNetworkAcl

  NaclAssociationPublicSubnet2:
    Type: AWS::EC2::SubnetNetworkAclAssociation
    Properties:
      SubnetId: !Ref PublicSubnet2
      NetworkAclId: !Ref CustomNetworkAcl

  NaclAssociationPrivateSubnet1:
    Type: AWS::EC2::SubnetNetworkAclAssociation
    Properties:
      SubnetId: !Ref PrivateSubnet1
      NetworkAclId: !Ref CustomNetworkAcl

  NaclAssociationPrivateSubnet2:
    Type: AWS::EC2::SubnetNetworkAclAssociation
    Properties:
      SubnetId: !Ref PrivateSubnet2
      NetworkAclId: !Ref CustomNetworkAcl

  NaclAssociationProtectedSubnet1:
    Type: AWS::EC2::SubnetNetworkAclAssociation
    Properties:
      SubnetId: !Ref ProtectedSubnet1
      NetworkAclId: !Ref CustomNetworkAcl

  NaclAssociationProtectedSubnet2:
    Type: AWS::EC2::SubnetNetworkAclAssociation
    Properties:
      SubnetId: !Ref ProtectedSubnet2
      NetworkAclId: !Ref CustomNetworkAcl

  S3FlowLog:
    Type: AWS::EC2::FlowLog
    Condition: EnableS3VPCFlowLog
    Properties:
      ResourceId: !Ref VPC1
      ResourceType: VPC
      TrafficType: ALL
      LogDestinationType: s3
      LogDestination: !Sub 'arn:aws:s3:::${DestinationVPCFlowLogBucketName}'
      Tags:
        - Key: Name
          Value: sample-vpc-s3-flow-log

  CloudWatchLogsFlowLog:
    Type: AWS::EC2::FlowLog
    Condition: EnableCloudWatchLogsVPCFlowLog
    Properties:
      ResourceId: !Ref VPC1
      ResourceType: VPC
      TrafficType: ALL
      LogDestinationType: cloud-watch-logs
      LogDestination: !Sub 'arn:aws:logs:ap-northeast-1:${AWS::AccountId}:log-group:/aws/vpc/flow-logs'
      Tags:
        - Key: Name
          Value: sample-vpc-cloudwatch-logs-flow-log

FlowLogsLogGroup:
    Type: AWS::Logs::LogGroup
    Condition: EnableCloudWatchLogsVPCFlowLog
    Properties:
      LogGroupName: /aws/vpc/flow-logs
      RetentionInDays: 90
      Tags:
        - Key: Name
          Value: sample-vpc-flow-logs-log-group

  FlowLogsIAMRole:
    Type: AWS::IAM::Role
    Condition: EnableVPCFlowLog
    Metadata:
      cfn_nag:
        rules_to_suppress:
          - id: W28
            reason: "IAM role name is specified as a fixed value."
      guard:
        SuppressedRules:
          - IAM_NO_INLINE_POLICY_CHECK
    Properties:
      RoleName: sample-flow-logs-role
      AssumeRolePolicyDocument:
        Version: 2012-10-17
        Statement:
          - Effect: Allow
            Principal:
              Service:
                - vpc-flow-logs.amazonaws.com
            Action:
              - sts:AssumeRole
      Path: /
      Policies:
        - PolicyName: FlowLogsS3Policy
          PolicyDocument:
            Version: 2012-10-17
            Statement:
              - Effect: Allow
                Action:
                  - s3:PutObject
                Resource: !Sub 'arn:aws:s3:::${DestinationVPCFlowLogBucketName}/*'
        - PolicyName: FlowLogsCloudWatchLogsPolicy
          PolicyDocument:
            Version: 2012-10-17
            Statement:
              - Effect: Allow
                Action:
                  - logs:CreateLogGroup
                  - logs:CreateLogStream
                  - logs:PutLogEvents
                  - logs:DescribeLogGroups
                  - logs:DescribeLogStreams
                Resource: !Sub "arn:aws:logs:ap-northeast-1:${AWS::AccountId}:log-group:/aws/vpc/*"

Outputs:
  VPCId:
    Value: !Ref VPC1
    Export:
      Name: SampleVPCId

  PublicSubnet1Id:
    Value: !Ref PublicSubnet1
    Export:
      Name: SamplePublicSubnet1Id

  PublicSubnet2Id:
    Value: !Ref PublicSubnet2
    Export:
      Name: SamplePublicSubnet2Id

  PrivateSubnet1Id:
    Value: !Ref PrivateSubnet1
    Export:
      Name: SamplePrivateSubnet1Id

  PrivateSubnet2Id:
    Value: !Ref PrivateSubnet2
    Export:
      Name: SamplePrivateSubnet2Id

  ProtectedSubnet1Id:
    Value: !Ref ProtectedSubnet1
    Export:
      Name: SampleProtectedSubnet1Id

  ProtectedSubnet2Id:
    Value: !Ref ProtectedSubnet2
    Export:
      Name: SampleProtectedSubnet2Id
